The M16 (more formally Rifle, Caliber 5.56 mm, M16) is the United States Military designation for the AR-15 rifle. Colt purchased the rights to the AR-15 from ArmaLite and currently uses that designation only for semi-automatic versions of the rifle. The M16 fires the 5.56x45mm cartridge. The M16 entered United States Army service and was deployed for jungle warfare operations in South Vietnam in 1963, becoming the U.S. Military's standard service rifle of the Vietnam War by 1969, replacing the M14 rifle in that role. The U.S. Army retained the M14 in CONUS, Europe, and South Korea until 1970. Since the Vietnam War, the M16 rifle family has been the primary service rifle of the U.S. Military.
 |
| M-16 Rifle |
 |
| M-16 Rifle |
 |
| M-16 Rifle |
The M16 has been widely adopted by militaries around the world. Total worldwide production of M16-style weapons since the design's inception has been approximately 8 million, making it the most produced firearm of its caliber. The M16 is being phased out in the United States Army and being replaced by the M4 carbine, which is itself a shortened derivative of the M16A2, as of 2010. M16 replacement by the Individual Carbine could come in 2014 if procurement is attained.
M-16 Introduction
The M16 is a lightweight, 5.56 mm, air-cooled, gas-operated, magazine-fed assault rifle, with a rotating bolt, actuated by direct impingement gas operation. The rifle is made of steel, 7075 aluminum alloy, compositeplastics and polymer materials.
The U.S. Air Force's rifle, the M16, and the United States Marine Corps and Army rifle, the XM16E1, were the first versions of the M16 rifle fielded. Soon, the U.S. Army standardized the XM16E1 as the M16A1 rifle, an M16 with a forward assist feature requested by the Army. All of the early versions were chambered to fire the M193/M196 cartridge in the semi-automatic and the automatic firing modes. This occurred in the early 1960s, with the Army issuing it in late 1964. Commercial AR-15s were first issued to Special Forces troops in spring of 1964.
The M16A3 rifle is an M16A2 rifle with an M16A1's fire control group (semi-automatic fire, automatic fire) that is used only by the U.S. Navy.
 |
| M-16 Rifle |
 |
| M-16 Rifle |
The M16A4 rifle was standard issue for the United States Marine Corps in Operation Iraqi Freedom; it replaced the M16A2 in front line units. In the U.S. Army the M16A2 rifle is being supplemented with two rifle models, the M16A4 and the M4 carbine as the standard issue assault rifle. The M16A4 has a flat-top receiver developed for the M4 carbine, a handguard with four Picatinny rails for mounting a sight, laser, night vision device, forward handgrip, removable handle, or a flashlight.
The M16 rifle is principally manufactured by Colt and Fabrique Nationale de Herstal (under a U.S. military contract since 1988 by FNH-USA; currently in production since 1991, primarily M16A2, A3, and A4), with variants made elsewhere in the world. Versions for the U.S. military have also been made by H & R Firearms General Motors Hydramatic Division and most recently by Sabre Defence. Semi-automatic versions of the AR-15 are popular recreational shooting rifles, with versions manufactured by other small and large manufacturers in the U.S.
M-16 Design:
The M16's receivers are made of 7075 aluminum alloy, its barrel, bolt, and bolt carrier of steel, and its handguards, pistol grip, and buttstock of plastics. Early models were especially lightweight at 6.5 lb (2.9 kg) without magazine and sling. This was significantly less than older 7.62 mm "battle rifles" of the 1950s and 1960s. It also compares with the 6.5 lb (2.9 kg) AKM without magazine.[35] M16A2 and later variants (A3 & A4) weigh more (8.5 lb (3.9 kg) loaded) because of the adoption of a thicker barrel profile.
 |
| M-16 Rifle |
 |
| M-16 Rifle |
 |
| M-16 Rifle Mail Mount |
The thicker barrel is more resistant to damage when handled roughly and is also slower to overheat during sustained fire. Unlike a traditional "bull" barrel that is thick its entire length, the M16A2's barrel is only thick forward of the handguards. The barrel profile under the handguards remained the same as the M16A1 for compatibility with the M203 grenade launcher. The rifle is the same length as the M16A2.
 |
| M-16 Rifle Parts |
The M16 rifle fires the 5.56x45mm cartridge and can produce massive wounding effects when the bullet impacts at high velocity and yaws in tissue leading to fragmentation and rapid transfer of energy.This produces wounds that were so devastating that the International Committee of the Red Cross (ICRC) and many countries (Austria, Argentina, Belgium, Bolivia, Bulgaria, Burundi, Cambodia, Cyprus, Germany, Ireland, Latvia, Lithuania, Luxembourg, Mauritius, Mexico, Romania, Samoa, Slovenia, Sweden, Switzerland, etc.) considered the M16 to be an inhumane weapon.
One distinctive ergonomic feature is a plastic or metal stock directly behind the action, which contains a recoil spring. This serves the dual function of operating spring and recoil buffer. The stock being in line with the bore reduces muzzle rise, especially during automatic fire. Because recoil does not significantly shift the point of aim, faster follow-up shots are possible and user fatigue is reduced.
Another distinctive ergonomic feature is a carrying handle on top of the receiver, with an integrated rear sight assembly and charging handle. This design is a by-product of the original design where the carry handle served to protect the charging handle and mount a scope.[43] In practice, the handle is rarely used to carry the weapon and doing so is expressly prohibited in many military organizations, as it is considered unsafe. Holding the weapon by the pistol grip provides quicker response time and better "muzzle awareness," while a shoulder sling provides a more convenient option when response time is not a concern.[] The "accessory rail" is also considered unsafe to use after the weapon has been fired for prolonged periods as enough heat, to melt flesh, will transfer from the receiver to the handle. More importantly, with the sight plane 2.5 in (63.5 mm) over the bore, the M16 has an inherent parallax problem that can be confounding to shooters. At closer ranges (typically inside 15–20 meters), the shooter must aim high in order to place shots where desired.
Newer models have a "flattop" upper receiver with a Picatinny rail, to which the user can attach either a conventional sighting system or numerous optical devices such as night vision scopes.
The M16 utilizes direct impingement gas operation; energy from high-pressure gas tapped from a non-adjustable port built into the front sight assembly actuates the moving parts in the weapon. Combustion gases travel via a gas tube above the barrel directly into a chamber in the bolt carrier behind the bolt itself, pushing the carrier away from the bolt. This reduces the number of moving parts by eliminating the need for a separate piston and cylinder and it provides better performance in rapid fire by keeping reciprocating masses on the same axis as the bore.
 |
| M-16 Rifle Review |
The primary criticism of direct impingement is that fouling and debris from expended gunpowder is blown directly into the breech. As the superheated combustion gas travels down the tube, it expands and cools. This cooling causes vaporized matter to condense as it cools depositing a much greater volume of solids into the operating components of the action. The increased fouling can cause malfunctions if the rifle is not cleaned as frequently as should be. The amount of sooting deposits tends to vary with powder specification, caliber, and gas port design.
In April 2010 TACOM Life Cycle Management Command issued permission for soldiers to camouflage M4/M16 weapons with paint if given command approval.
